    "Trabecula" Application
    Authors: E.A. Shishkina, Yu. S. Timofeev
    The generator of bone segment geometry TRABECULA is a convenient tool for constructing computational phantoms of human hematopoietic sites with consequent dosimetry application, viz., for evaluation of energy deposition in bone marrow targets per emitted particle.

    The energy deposition per emitted particle is recalculated to a skeletal-average dose factor, converting the radionuclide activity concentration in the cortical or trabecular bone to the value of dose rate in bone marrow.

    The software is designed for scientists and engineers working in the bone marrow dosimetry.

    A useful feature of Trabecula software is its ability to generate output files that are ready to be exported to MCNP (Monte Carlo N-Particle Transport Code).


    • The program is designed for use on IBM PC compatible computers running Windows XP SP2 (and above), Windows Vista, Windows 7, 8, 10.
    • Programming Language Java
    • Program volume 11.6 MB
    • Certificate of State registration of the program № 2019617010 dated 03.06.2019.
    The program requires Java Runtime Environment version 8.0 or higher installed. Use a command file «trabecula.bat» to start. Details of software possibilities and requirements for input data as well as a brief description of the algorithm for constructing computational phantoms are given in the document «Рандомизированный генератор вычислительных фантомов.pdf».
    When using the program, please refer to the website:
    «Shishkina E.A., Timofeev Yu.S. http://www.urcrm.ru/trabecula»

    If you find any bugs in the program, please, contact swimmer_86@mail.ru.

    Download link (build date - 19.12.2020): trabecula
    Web: http://www.urcrm.ru/trabecula
